PRODUCT FEATURES
• Power size: Power adjustable 2-4, by spring
• Body material: Aluminium
• Arm set type / material: Scissor / Steel
• Functions: Tested functions – Closing, latching speed and backcheck for installation on:
– Door mount pull (Fig 1)
– Door mount push (Fig 6)
– Frame mount push (Fig 61) installed with no head projection only Note: If Fig 61 installation includes head projection, backcheck is not suitable for use on fire resistant doors.
• Non-tested functions:
– Delayed action (All fitting positions)
– Backcheck when installed on frame mount push (Fig 61) with head projection
• Maximum door weight: 80kgs (door mount pull, frame mount push) 60kgs (door mount push)
• Maximum door width: 1100mm (door mount pull, frame mount push) 950mm (door mount push)
• Performance Testing: Successfully tested in accordance with the requirements of BS EN1154: 1997
• Successfully tested in accordance with the opening force recommendations and requirements contained within BS 8300 / Approved Document M for door closing devices and is suitable for the following minimum door widths:
– Door mount pull (Fig 1) = 857mm
– Door mount push (Fig 6) = 689mm
– Frame mount push (Fig 61) – No head projection = 917mm
– Frame mount push (Fig 61) – 50mm head projection = 910mm

FIRE TESTING
• Successfully fire tested in accordance with the
requirements of BS EN1634-1, suitable for use on
30, 60, 90 and 120 minute timber fire doors

CERTIFICATION
• UKCA marked (Certificate AD7992)
• CE marked (Certificate AD7994)
• CERTIFIRE approved (Certificate CF6103)
